Multiband HFÂ V configuration
Prosistel PST-1524TV (6-10-15-20-40m) V-Dipole
The independent traps give a better performance in terms of the possibility of adjusting band by band and bandwidth helpful.
Â
Heavy duty construction with stainless steel bolts, traps made with copper wire on fiberglass insulators allow to use it even with power up to 2kW pep.
Â
For optimal performance, it may want to mount it to a height of at least 4-5m from the ground.
It works just as well also to 2m from the ground. We recommend the use of 1: 1 balun.
Being practically omni directional, it does not require rotator.
Â
Specifications:
– Gain = 0 dBd
– Impedance = 50 ohm
– ROS = <1:1,2 extremes of bandwidth within 1: 1.8
– Rotating radius = 3 to about 4m depends on the version
– Weight = about 6-8kg
– Accept mast 48mm (standard) or 60mm (optional)
– Material = AL6060T6, stainless steel bolts.
