Vine Antennas AS-HF-OCF-40 | Off Centre Fed Dipole

AS-OCF LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-HF-OCF-40 | Off Centre Fed Dipole

AS-OCF 2 LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

A traditional Dipole is a half-wavelength radiator, fed in the Centre with two equal length legs, the Off-Centre-Fed Dipole is a Dipole whose feedpoint is at a point removed from the centre of the antenna.

A traditional dipole is fed in the centre with 50-ohm coax, or more correctly through a 1:1 balun, whereas the off-centre fed dipole is fed through a 4:1 balun.

Specification

Bands:

40M, 20M, 15M, 10M (without ATU)
30M, 17M, 12M (with ATU)

Power: 200W Max



Overall Length 63′ 6″

Overall Length 19.3548m

















Vine Antennas AS-HF-OCF-LITE | Lightweight OCF Dipole

AS-OCF-LITE LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-HF-OCF-LITE | Lightweight OCF Dipole

OCF-LITE 2 LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-HF-OCF-LITE

An Off-Centre Fed Dipole for
40M, 20M, 15M & 10M (no tuner)
30M, 17M, 12M (with tuner)



What’s an Off-Centre Fed Dipole?

A traditional Dipole is a half-wavelength radiator, fed in the Centre with two equal length legs, the Off-Centre-Fed Dipole is a Dipole whose feedpoint is at a point removed from the centre of the antenna.

A traditional dipole is fed in the centre with 50-ohm coax, or more correctly through a 1:1 balun, whereas the off-centre fed dipole is fed through a 4:1 balun.



Why Off-Centre Feed a Dipole?

By moving the feedpoint of the dipole from the centre to off-centre, we create a multi-band antenna with multiple resonant points. We also change the feedpoint impedance and therefore need a carefully designed balun to provide a match to 50 ohms.

A centre fed dipole is only resonant at one single frequency, the off-centre fed dipole is resonant on multiple frequencies.

Your AS-HF-OCF-40 has been tested for resonance and is resonant on the 40M, 20M, 15M and 10M amateur bands and needs no ATU.

The antenna also offers a reasonable match on the 12M, 17M and 30M amateur bands but must be used with an ATU

Where is it Resonant?

By careful design of the balun and feedpoint of the antenna, your AS-HF-OCF-LITE has the following SWR from 0 – 30MHz:



Specification

Bands:   40M, 20M, 15M, 10M (without ATU)
30M, 17M, 12M (with ATU)

Power: 100W Max

OCF-Lite

Overall Length 63 9″

Overall Length 19.3548m











Vine Antennas AS-Urban-Portable 40-10m | High Power

AS-EF-33-HP KIT HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-EF-33-HP | High Power End Fed Antenna Kit

EF-33-HP 1 LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-EF-33-HP

An End-Fed Antenna Kit
40M to 10M (ATU Advisable)

What’s an End-Fed?

An end-fed antenna is tuned against ground whereby the physical ground forms half of a theoretical dipole.

This is a kit to enable you to construct an end-fed antenna in limited space.



Installation Suggestion

Drive the provided earth rod into the ground leaving about 6-9” protruding. Slip the eye ring of the balun over the earth rod and connect the rod to the green terminal with the cable provided. Take the wire at an angle to the top of a support to create a sloping antenna.`



Where is it Resonant?

By careful design of the balun and length of the antenna, your AS-EF-33-HP has the following SWR from 0 – 30MHz:



Specification

Bands: 40M to 10M

ATU Advisable

Power: 1Kw pep Max (balun rating)



























Vine Antennas AS-CW-40-HP | High Power Carolina Windom

AS-CW HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CW-40-HP | High Power Carolina Windom

AS-CW 3 LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CW-40-HP | High Power Carolina Windom

A Windom Antenna for
40M, 20M, 10M



What’s a Carolina Windom?

Think of a Carolina Windom as an upside-down vertical antenna. The horizontal section is the counterpoise, and the vertical radiator the main antenna.

Because the antenna is not fed at its centre, the RF currents in each horizontal radiating section are very much unequal. This makes the vertical coaxial feedline radiate RF energy and become part of the antenna. This results in a very effective omni-directional radiation pattern and also an excellent general-purpose antenna for the SWL.

How Should I Use It?

The antenna should be installed as high as possible and clear from other nearby objects. The vertical radiator must not be close to metal objects (like masts) and should be in free air.

Where is it Resonant?

By careful design of the antenna, the Carolina Windom has resonant points in the 40M, 20M and 10M amateur bands. The antenna can also be used in other HF bands with the use of an ATU.



Specification

Bands: 40M, 20M, 10M
(without ATU)

30M, 17M, 15M, 12M

(with ATU)

Power: 1Kw Max

Windom 40

Overall Length 66′

Overall Length 41.7576m







Vine Antennas AS-CW-80-HP | High Power Carolina Windom

AS-CW HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CW-80-HP | High Power Carolina Windom

AS-CW 1 LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio



Vine Antennas AS-CW-80-HP | High Power Carolina Windom

A Windom Antenna for
80M,40M, 20M, 10M



What’s a Carolina Windom?

Think of a Carolina Windom as an upside-down vertical antenna. The horizontal section is the counterpoise, and the vertical radiator the main antenna.

Because the antenna is not fed at its centre, the RF currents in each horizontal radiating section are very much unequal. This makes the vertical coaxial feedline radiate RF energy and become part of the antenna. This results in a very effective omni-directional radiation pattern and also an excellent general-purpose antenna for the SWL.

How Should I Use It?

The antenna should be installed as high as possible and clear from other nearby objects. The vertical radiator must not be close to metal objects (like masts) and should be in free air.

Where is it Resonant?

By careful design of the antenna, the Carolina Windom has resonant points in the 40M, 20M and 10M amateur bands. The antenna can also be used in other HF bands with the use of an ATU.



Specification

Bands:

80M, 40M, 20M, 10M
(without ATU)

30M, 17M, 15M, 12M

(with ATU)

Power: 1Kw Max



Windom 80

Overall Length 132′





Vine Antennas AS-CW-80 | Carolina Windom

AS-CW HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CW-80 | Carolina Windom

AS-CW 3 LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CW-80 | Carolina Windom

A Windom Antenna for
80M/40M/20M/10M



What’s a Carolina Windom?

Think of a Carolina Windom as an upside-down vertical antenna. The horizontal section is the counterpoise, and the vertical radiator the main antenna.

Because the antenna is not fed at its centre, the RF currents in each horizontal radiating section are very much unequal. This makes the vertical coaxial feedline radiate RF energy and become part of the antenna. This results in a very effective omni-directional radiation pattern and also an excellent general-purpose antenna for the SWL.

How Should I Use It?

The antenna should be installed as high as possible and clear from other nearby objects. The vertical radiator must not be close to metal objects (like masts) and should be in free air.

Where is it Resonant?

By careful design of the antenna, the Carolina Windom has resonant points in the 40M, 20M and 10M amateur bands. The antenna can also be used in other HF bands with the use of an ATU.



Specification

Bands: 80M,40M, 20M, 10M
(without ATU)

30M, 17M, 15M, 12M

(with ATU)

Power: 200W Max

Windom 80

Overall Length 132′





Vine Antennas AS-CW-40 | Carolina Windom

AS-CW HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CW-40 | Carolina Windom

AS-CW 3 LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CW-40 | Carolina Windom

A Windom Antenna for
40M, 20M, 10M



What’s a Carolina Windom?

Think of a Carolina Windom as an upside-down vertical antenna. The horizontal section is the counterpoise, and the vertical radiator the main antenna.

Because the antenna is not fed at its centre, the RF currents in each horizontal radiating section are very much unequal. This makes the vertical coaxial feedline radiate RF energy and become part of the antenna. This results in a very effective omni-directional radiation pattern and also an excellent general-purpose antenna for the SWL.

How Should I Use It?

The antenna should be installed as high as possible and clear from other nearby objects. The vertical radiator must not be close to metal objects (like masts) and should be in free air.

Where is it Resonant?

By careful design of the antenna, the Carolina Windom has resonant points in the 40M, 20M and 10M amateur bands. The antenna can also be used in other HF bands with the use of an ATU.



Specification

Bands: 40M, 20M, 10M
(without ATU)

30M, 17M, 15M, 12M

(with ATU)

Power: 200W Max

Windom 40

Overall Length 66′

Overall Length 41.7576m





















Vine Antennas AS-CITY-80 | End Fed City Windom

AS-CITY HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CITY-80 | End Fed City Windom

AS- CITY 2 Vine Antennas RST-BBB LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio



Vine Antennas AS-CITY-80 | End Fed City Windom

An End Fed Antenna for
80M, 40M, 20M, 15M, 10M



What’s a City Windom?

A city windom is a unique end-fed antenna design featuring a long wire plus a resonant matching network comprising a balun, a length of RG-58 and a line isolator.

The City-Windom behaves much like a normal Windom but is better suited to suburbia and can be suspended from a window to a suitable anchor point.



How Should I Use It?

There are three recommended configurations of the City Windom.

Option 1:

Sloper



Option 2:

Horizontal



Option 3:

‘L’ Configuration

Note: depending on your installation, antenna height above ground, angle of installation et cetera, the antenna may need peeking to resonance. Extra wire is included at the end of antenna but folded back to enable you to extend or shorten the antenna as necessary.

Where is it Resonant?

By careful design of the balun, matching network and matching network of the antenna, your City Windom has the following SWR from 0 – 30MHz:

Note: SWR plot from 40M variant

Specification

Bands:

80M, 40M, 20M, 15M, 10M
(without ATU)
30M, 17M, 12M (with ATU)

Power: 200W MCity 80 (‘L’)

City 80 (L)

Overall Length 113′ 6″

Overall Length 34.5948m

City 80  (flat)

Overall Length 137′ 9″

Overall Length 41.9862m













Vine Antennas AS-CITY-40-HP | High Power End Fed City Windom

AS-CITY-HP HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CITY-40-HP | High Power End Fed City Windom

AS-CITY-HP LEFT Vine Antennas RST-BBB LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio



Vine Antennas AS-CITY-40-HP

AS-CITY-40-HP

An End Fed Antenna for
40M, 20M, 15M, 10M



What’s a City Windom?

A city windom is a unique end-fed antenna design featuring a long wire plus a resonant matching network comprising a balun, a length of RG-58 and a line isolator.

The City-Windom behaves much like a normal Windom but is better suited to suburbia and can be suspended from a window to a suitable anchor point.



How Should I Use It?

There are three recommended configurations of the City Windom.

Option 1:

Sloper

Option 2:

Horizontal

Option 3:

‘L’ Configuration

Note: depending on your installation, antenna height above ground, angle of installation et cetera, the antenna may need peeking to resonance.



Where is it Resonant?

By careful design of the balun and feedpoint of the antenna, your AS-HF-OCF-40-HP has the following SWR from 0 – 30MHz:

Specification

Bands:  40M, 20M, 15M, 10M
(without ATU)

30M, 17M, 12M

(with ATU)

Power: 1Kw pep Max



City 40 (‘L’)

Overall Length 56′ 9″

Over Length 17.2974m

City 40 (flat)

Overall Length 68′ 9″

Overall Length 20.955m

​











































Vine Antennas AS-CITY-80-HP | High Power End Fed City Windom

AS-CITY-HP HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio

Vine Antennas AS-CITY-80-HP | High Power End Fed City Windom

AS-CITY-HP TOP Vine Antennas RST-BBB LAMCO Barnsley HAM Radio Shop Amateur Radio Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio



Vine Antennas AS-CITY-80-HP

AS-CITY-80-HP

An Off-Centre Fed Dipole for
80M, 40M, 20M, 15M & 10M (no tuner)
30M, 17M, 12M (with tuner)



What’s a City Windom?

A city windom is a unique end-fed antenna design featuring a long wire plus a resonant matching network comprising a balun, a length of RG-58 and a line isolator.

The City-Windom behaves much like a normal Windom but is better suited to suburbia and can be suspended from a window to a suitable anchor point.



How Should I Use It?

There are three recommended configurations of the City Windom.

Option 1:

Sloper

Option 2:

Horizontal

Option 3:

‘L’ Configuration

Note: depending on your installation, antenna height above ground, angle of installation et cetera, the antenna may need peeking to resonance.



Where is it Resonant?

By careful design of the balun and feedpoint of the antenna, your AS-HF-OCF-40-HP has the following SWR from 0 – 30MHz:

Specification

Bands:  80M, 40M, 20M, 15M, 10M
(without ATU)

30M, 17M, 12M

(with ATU)

Power: 1Kw pep Max

City 80 (L)

Overall Length 113′ 6″

Overall Length 34.5948m

City 80  (flat)

Overall Length 137′ 9″

Overall Length 41.9862m
