Anytone AT-D878UVII Plus | DMR/FM Handheld Transceiver

£199.95
AT-D878UVII Plus HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty
£199.95

In stock

Buy Now

Anytone AT-D878UVII Plus | DMR Handheld Radio | LAMCO Barnsley

878UVII Plus 7 HAM Radio Shop HAM Radio Shops Amateur Radio Shops Dealer Supplier Vine Antennas Amateur Radio Shops HAM Radio Dealer Supplier Retailer Second Hand Twelve Months Warranty, Amateur Radio Sales. HAM Radio Sales. HAM Radio Shop, HAM Radio Shops, Amateur Radio Dealers, HAM radio dealers UK. Icom, Kenwood, Yaesu, Hytera. HAM Radio Shops, Amateur Radio Shop, Icom, Hytera, Kenwood, Yaesu, Antennas, Antenna Tuners, Power Supplies, Coax, CB Radio, Scanners, Receivers, Short Wave, Barnsley, UK, Call 01226 361700, Yorkshire The HAM Radio Shop Amateur Radio Dealer Suppliers United Kingdom Two Way Radio Hire Two Way Radio Sales Repair Service Scanners CB Radio Receivers Short Wave Radio



Needs Programming





Package Includes:

  • Dual-band VHF/UHF Radio

  • 3100 mAh Extended Life lithium-ion battery

  • Desktop Charger w/ AC adapter

  • Dual-band antenna

  • Belt clip

  • USB Programming Cable

  • Downloadable Software User Manual.



Details

Anytone AT-D878UVII Plus BLUETOOTH Digital DMR Dual-band Handheld Commercial Radio with Roaming and GPS VHF/UHF Dual-band Digital/Analog Part 90 DMR commercial transceiver with 1.77-inch colour TFT display and GPS.

The new AT-D878 model includes DMR Roaming, a faster processor and more significant memory for future enhancements. Ideal for Fire, Search & Rescue, EMS, Police, Sheriff, Forestry and Security operations. Frequency coverage 140-174 / 400-480 MHz.

  • Roaming: Built-in DMR Repeater Roaming feature
  • APRS / GPS Capable : DMR-APRS and Analog APRS Capable (GPS)
  • VHF/UHF Dual Band: Monitor two bands at the same time (V+V, U+U & V+U)
  • Digital DMR and Analog: Features both DMR digital and analogue modes on any channel.
  • High Power Output : 6.0W, 4.0W, 2.5W, 1.0W selectable TX power output
  • 2 & 5 Tone Paging Includes built-in: 2 Tone and 5 Tone Paging feature
  • Programming Cable: Includes USB Programming Cable, free software available for download.
  • Colour TFT Display:1.77 inch colour TFT screen for Day or Night operation. User-changeable display and font colours.
  • Roaming: New Built-in Roaming Feature
  • APRS (GPS): DMR-APRS and Analog APRS Capable (GPS)
  • Processor: Faster Processor over the D868UV
  • Additional Memory: Larger Memory for Future Enhancements TFT Display Background Display and Font Colors are User changeable
  • Digital Monitor: Monitor One or Two Timeslots
  • Zone Select: Selectable Zones from Keypad
  • Auto RX Mode Receiver: Auto Selects to incoming Digital or Analog Signal
  • GPS: Built-in GPS feature
  • Memory Channels: 4,000 channels
  • DMR Talk Groups: 10,000
  • Digital Contacts: 150,000 (complete worldwide database from DMR-MARC)
  • Power Levels: 4 programmable power levels: 6/4/2.5/1 Watt Transmit Power Levels.
  • Zones: 250 zones, up to 250 channels per zone.
  • Display: 1.77-inch colour TFT Screen with the selectable dual channel or single channel display.
  • Battery: Operate 35+ hours between charges with the supplied 3100 mAh lithium-ion battery in the power saver mode.
  • Bandwidth: 12.5 / 25.0 kHz Analog, and 12.5 kHz DMR
  • Import/Export: Enhanced CPS allows direct input and export of channels, digital IDs and talk groups.
  • DMR Compatibility: Supports Tier I and Tier II operation, making it compatible with DMR repeaters that utilize two-slot TDMA technology.
  • Amateur Radio: Also operational on amateur radio DMR networks and analogue frequencies. Software importable worldwide amateur contact database.
  • Programmable: FCC 47CFR90.203 requires the keypad to be locked in the shipping configuration. Software keypad unlocking and re-programming are available with the included USB Programming Cable.
  • Speaker Connection:2-pin style Kenwood/Wouxun type earphone and speaker mic connection for a variety of accessories.
  • Quiet Tones: CTCSS/DCS tone squelch with split tone and custom tone capability.
  • Frequency Range: 140-174 / 400-480 MHz RX/TX







General
Frequency Range

Europe: 144-146MHz(V),430-440MHz(U)

United State: 136-174MHz(V),400-480MHz(U)
Australia: 144-148MHz(V), 420-450MHz(U)
India:144-146MHz(V), 436-438MHz(U)
Channel Capacity
4000 channels
Channel Spacing
25KHz (Wide Band) ,12.5KHz (Narrow Band)
Phase-locked Step
5KHz, 6.25KHz
Operating Voltage
7.4V DC ±20% /(2100mAh/3100mAh)
Frequency Stability
±2.5ppm
Operating Temperature
-20℃~ +55℃
Size
129×61×39mm (with battery pack)
Weight
282g (with battery pack, antenna)
Receiving Part
Wide band
Narrow band
Sensitivity(12dB SINAD)
≤0.25μV
 ≤0.35μV
Digital Sensitivity
0.3uV/-117.4dBm (BER 5%)      0.7uV/-110dBm (BER 1%)
Adjacent Channel Selectivity
≥70dB
 ≥60dB
Spurious Emission
≤-57dB
≤-57dB
Spurious Rejection
≥70dB
≥70dB
Blocking
84db
Hum & Noise
≥45dB
≥40dB
Audio Distortion
≤5%
Audio Power Output
1000mW/16Ω
Transmitting Part
Wide band
Narrow band
Power Output
VHF: 7/5/2.5/1W,        UHF: 6/5/2.5/1W
Modulation
±5.0KHz@25KHz
±2.5KHz@12.5KHz
Adjacent Channel Power
≥70dB
≥60dB
Hum & Noise
≥40dB
≥36dB
Spurious Emission
≤-36dBm
≤-36dBm
4FSK Digital Modulation

12.5KHz（data）7K60FXD

12.5KHz（data+voice）7K60FXE
Audio Distortion
≤5%
Error rate
≤3%
