Yaesu FT-4XE – VHF/UHF Dual Band FM Handheld Transceiver

Overview

The Yaesu FT-4XE is a compact, rugged VHF/UHF handheld transceiver designed for reliable, everyday communication. With up to 5 watts of output power, a powerful 1W speaker, and long battery life, the FT-4XE is ideal for both amateur radio operators and commercial users. Despite its small size, the FT-4XE is packed with versatile features including wide receive coverage, scanning options, weather alerts, VOX support, and PC programming.

Key Features

• Dual Band VHF/UHF Handheld Transceiver

  • Transmit: 144–148 MHz / 400–480 MHz

  • Receive: 65–108 MHz (FM radio), 136–174 MHz, 400–480 MHz

• Selectable Output Power: 5W, 2.5W, or 0.5W

• 1-Watt Loud Audio: Clear and crisp sound from a front-facing speaker

• High-Capacity Battery:

  • Supplied 1750mAh Li-ion battery

  • Up to 15 hours operation (5:5:90 duty cycle)

  • Includes SBH-22 3.5-hour rapid charger

• VOX Support: Hands-free operation with optional SSM-512B earpiece mic

• Programmable Scanning:

  • VFO Scan, Memory Scan, and Priority Channel Scan

  • Weather Alert Scan with severe weather notifications

• PC Programmable: Optional SCU-35 programming cable and software

• Transceiver Cloning: Optional SCU-36 cable for easy radio-to-radio cloning

• Other Features:

  • CTCSS/DCS tone support

  • DTMF operation

  • ARTS (Automatic Range Transponder System)

  • Busy Channel Lockout (BLCO)

  • Transmit Time-Out Timer (TOT)

  • Automatic Power Off (APO)

  • Keypad entry and FM broadcast receiver

• Compact and Durable:

  • Size: 2.1 x 3.5 x 1.2 inches (excluding knobs and antenna)

  • Weight: 8.82 oz

Performance Highlights

Powerful Outputs

The Yaesu FT-4XE delivers a full 5 watts of RF output to ensure your signal is heard. Its oversized front speaker provides 1 watt of clear, high-quality audio — ideal for noisy environments or field use.

Extended Battery Life

Equipped with a robust 1750mAh lithium-ion battery, the FT-4XE offers over 9 hours of continuous operating time. Included with the radio is the SBH-22 rapid desktop charger for quick recharging in just 3.5 hours.

Advanced Scanning Options

The radio supports a wide variety of scanning modes, including:

• Programmable VFO Scan for entire frequency ranges

• Memory Scan for stored channels

• Priority Channel Scan to keep tabs on important frequencies

• Weather Alert Scan to warn you of severe conditions

PC and Clone Programming

Easily configure advanced settings on the Yaesu FT-4XE using the optional SCU-35 programming cable and software. For cloning between radios, use the SCU-36 clone cable.

Rich Feature Set in a Small Package

Despite its compact size, the FT-4XE is loaded with functionality such as DTMF keypad dialing, CTCSS/DCS encoding, time-out timer, and the Automatic Range Transponder System (ARTS) to alert you when you’re within communication range of other equipped radios.

Yaesu FT-4XE Compatible Accessories

Antennas

• SRA-15: Standard antenna for dual-band operation

Batteries

• SBR-28LI: 7.4V, 1750mAh Li-ion battery (included)

Brackets & Clips

• SHB-18: Durable belt clip

Chargers

• SAD-26B: AC adapter cable

• SBH-22: Desktop rapid charging cradle (included)

Microphones

• SSM-17B: Speaker microphone (replaces SSM-16B)

• SSM-512B: VOX earpiece microphone for hands-free use

Programming & Cloning

• SCU-35: USB programming cable for PC configuration

• SCU-36: Cloning cable for transceiver-to-transceiver cloning

Ideal For:

• Amateur radio operators seeking a lightweight, durable HT

• Emergency preparedness kits and outdoor communication

• Field work and daily VHF/UHF comms on the go
